Novastar MRV216 Receiver Card

The Novastar MRV216 is a high-performance universal receiving card designed to enhance LED display quality and stability. With a maximum load capacity of 512×384 pixels, it ensures sharp, high-resolution visuals. The MRV216 is equipped with brightness correction, fast line adjustment, 3D support, and RGB independent gamma adjustment, optimizing display effects for an enhanced viewing experience.

This receiver card features 16 standard HUB75E interfaces and supports up to 32 sets of RGB data, ensuring reliable performance in diverse environments. Its high stability and precise brightness adjustments make it a versatile choice for LED display applications.

Key Features:

• High-Resolution Support

  • Supports a maximum load of 512×384 pixels for detailed and crisp visuals.

• Enhanced Display Adjustments

  • Brightness correction and fast line adjustment for optimized screen performance.

  • 3D functionality and RGB independent gamma adjustment for superior visual effects.

• Reliable and Efficient Communication

  • 16 standard HUB75E interfaces for seamless data transmission.

  • Supports up to 32 sets of RGB data, ensuring flexibility and stability.

Specifications:

• Input Voltage: DC 3.3V – 5.5V

• Constant Current: 0.5A

• Rated Power: 2.5W

• Operating Temperature: -20°C to +70°C

• Humidity Range: 10% RH to 90% RH (non-condensing)

• Storage Temperature: -25°C to +125°C

• Size: 14.5mm × 91.5mm × 18.4mm

• Weight: 100.5g

• Certifications: RoHS, EMC Class A

The Novastar MRV216 is a versatile, stable, and high-performance receiving card, making it an ideal choice for delivering exceptional LED display quality across various applications.
