Colorlight A200 Cloud Networking Player

Technical Specifications

• Dimensions: 234.8 × 137.4 × 26 mm
• Weight: 0.9 kg
• Operating Voltage: DC 12V
• Power Consumption: 12W (rated)
• Operating Temperature: -20°C to +65°C
• Ambient Humidity: 0–95% (non-condensing)
• Storage: 8GB (4GB available for user)
• Pixel Capacity: 2.3 million pixels
• Max Resolution:
  • Sync Mode: 4096 × 2560 pixels (width/height)
  • Async Mode: 1920×1200@60Hz (up to 4096 width or 2560 height)

Key Features

1. Dual Playback Modes
   • Synchronous Display: Real-time content mirroring.
   • Asynchronous Playback: Scheduled/local content with mode priority settings.
2. 4K Hardware Decoding
   • Supports 4K 10-bit H.265/H.264 and 4K VPG decoding for high-quality video processing.
3. Cloud Platform Integration
   • Built on Colorlight Cloud Platform for:
     • Remote player monitoring | Program creation/scheduling
     • Centralized content publishing | Multi-level user management
4. Versatile Connectivity
   • Network options: Wi-Fi, LAN, 4G module (optional).
   • USB playback support for offline content.
5. Scalable Output & Compatibility
   • Sync-signal scaling for flexible display configurations.
   • Audio output for synchronized multimedia playback.
   • Fully compatible with conventional synchronous control systems.

Applications

• Digital signage in retail, transportation, or corporate environments.
• Large-scale LED displays requiring cloud-managed content distribution.
• Events needing hybrid synchronous/asynchronous playback control.
